UTM：UTM-1000

Despite e-commerce’s worldwide potential, it brings along with itself various nuisances and security risks such as spam, viruses, Trojans, hacker attacks, etc.

Accordingly, Nusoft presents you with UTM-1000, the ultimate solution to spammers, viruses, network security and management concerns. Its multi-layered spam filtering and training mechanisms help enterprises filter out unwanted emails, merely keep the essential ones. As for malicious code such as Trojans, worms and viruses, all can be effectively kept out of the enterprise’s network using its inbuilt dual anti-virus engines (ClamAV and Sophos) along with IDP system, leaving hackers no chance and eliminating security threats once for all.

In addition, UTM-1000 also features SPI firewall, Web filtering, load balancing, QoS, application blocking, total VPN solution, etc., facilitating your network management with all the necessary utilities built into a single device. Better yet, all signatures are free of charge and have no user number limit, which drastically lowers down your ownership cost.

Saves the budget for implementing an IPv6-based gateway simply for IPv4-to-IPv6 address translation.
Assigns or groups LAN / WAN / DMZ interfaces based on network policy.
Meets business continuity needs: VPN trunking, link failover, high availability (HA), etc.
Secures emails with spam and virus filtering. What is more, IT administrators are provided with intuitive statistics and comprehensive loggings that present an insight into email handling.
Efficaciously protects your network from viruses, Trojans, spyware, phising frauds, and other kinds of malicious code originating from the Internet using dual anti-virus engines and IDP system.
Prohibits Web browsers and TCP/IP-based applications from being used for recreational purposes.
Fairly distributes network traffic to each connection using bidirectional load balancing capabilities along with policy-based routing.
Ensures VPN tunnels with high reliability and security.
Targets QoS mechanisms at individual or groups; enables companies to base bandwidth allocation on their policies.


Anti-Virus	Anti-Spam	Intrusion Detection & Prevention	SPI Firewall	Co-Defense System	Anomaly Traffic Detection	Total VPN Solution	Web-Based UI


Multi-WAN Load Balancing	Link Failover	Bandwidth Management	Application Blocking	Web Filtering	AAA Server	File Transfer Blocking	Policy- Oriented Management


Authentication Mechanisms	High Availability	Policy-Based Routing	Logging	Email Archive Access	Mail Notice

1.Full IPv6 Compatibility

The device is completely compatible with the mainstream Internet protocol of the future -- IPv6. There is no budget required for implementing another IPv6-based gateway simply for IPv4-to-IPv6 address translation.

2.Custom Network Interface Groups

Up to four network interfaces are available for defining as LAN, WAN, DMZ or network groups (groups are isolated from one another). Thus, UTM-1000 can serve as an internal firewall physically separating each subnet with its grouping feature. By so doing, it gives an extra layer of protection to your internal network and efficaciously prevents viruses or worms from spreading over the network.

3.Dual Virus-Scanning Engines

The inbuilt virus-scanning engines (ClamAV and Sophos) protect the enterprise’s network from over five thousand kinds of viruses, Trojans, spyware, phishing frauds, etc. In addition, the virus signatures are free of charge and have no user number limit, offering you the most up-to-date protection at a minimum ownership cost.

4.Comprehensive Mail Reports

IT administrators are provided with detailed logs and intuitively interpretable statistics for analyzing email handling, such as the outcome of spam filtering and virus scanning of a specific email.

5.Proactive Intrusion Detection and Prevention (IDP)

The IDP focuses on OSI layers 4 to 7 in inspecting for Internet attacks. In addition to blocking network-based security threats (updated every 30 minutes; self-defined signatures supported), the IT administrator will be instantly notified and presented with comprehensive reports for diagnosis upon occurrence of an attack.

6.High Spam-Filtering Accuracy

Spam filtering can reach 99% accuracy using spam training and multiple filtering mechanisms such as Fingerprint, Bayesian, Global/Personal Rule, Grey-/Black-/Whitelist, etc. Without the need for the IT administrator’s intervention, recipients may decide whether to retrieve quarantined mail through the Mail Notice generated by UTM-1000, greatly reducing the network management load.

7.Web Filtering Mechanism

The Web Filter employs a cloud-based URL database that has eight categories namely Anti-Social and Illegal, Pornographic and Abusive, Gaming and Gambling, Society and Commerce, Communication and Technology, Leisure, Information and Education, Other, and up to sixty-four subcategories. Website browsing now can be easily regulated by specifying simply the category instead of the URL, keyword, etc.
In addition to that, IT administrators are also allowed to restrict file transfers, MIME types and browser scripts, and will be provided with detailed logs and statistics for analysis.

8.In- / Outbound Load Balancing & PBR

The device can load-balance outbound traffic evenly across WAN ports based on various load-balancing algorithms. It efficaciously makes the most advantage of your bandwidth and ensures you with a reliable connection.
Besides outbound load balancing, it is also capable of inbound load balancing, which helps mitigate multiple webpage requests directed at your Web server by distributing them across multiple WAN connections, guaranteeing uninterrupted e-commerce.
Its policy-based routing (PBR) mechanism allows the IT administrator to assign specific WAN port for a specific purpose (or traffic).

9.Quality of Service (QoS) / Individual QoS

The QoS mechanisms allow IT administrators to base the bandwidth allocation on company’s network policy, preventing bandwidth being exhausted by minorities.

10.TCP/IP-Based Application Blocking

The use of instant messaging (both login and file transfer), peer-to-peer sharing, multimedia streaming, web-based mail service, online gaming, VPN tunneling, remote controlling, etc. now can be effortlessly regulated by the means of application blocking.

11.A Total VPN Solution

UTM-1000’s VPN trunking capability ensures redundancy and bandwidth integration to IPSec and PPTP tunnels, greatly increasing the connection speed and stability. In addition, its SSL (Web) VPN connections adopt Hardware Authentication technology to verify the identity of users using simply hardware information rather than login information. Remote users are now offered fast and easy SSL (Web) VPN access without the need for complex configurations.
Most third party firewall products lack advanced VPN connection management and therefore result in security risks. In comparison, UTM-1000 secures highly confidential business information carried over the VPN with IDP and virus detection and provides advanced management such as QoS and authentication.
